Product Summary
The CY7C1354B-166AXCT is a 3.3V, 256K x 36 Synchronous pipelined burst SRAM with No Bus Latency logic. It is designed specifically to support unlimited true back-to-back Read/Write operations without the insertion of wait states. The CY7C1354B-166AXCT is equipped with the advanced (NoBL) logic required to enable consecutive Read/Write operations with data being transferred on every clock cycle. This feature dramatically improves the throughput of data through the SRAM, especially in systems that require frequent Write/Read transitions. The CY7C1354B-166AXCT is pin compatible and functionally equivalent to ZBT device.
Parametrics
CY7C1354B-166AXCT absolute maximum ratings: (1)Storage Temperature: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –55℃ to +125℃; (3)Supply Voltage on VDD Relative to GND: –0.5V to +3.6V; (4)DC to Outputs in High-Z State: –0.5V to VDDQ + 0.5V; (5)DC Input Voltage: –0.5V to VDDQ + 0.5V; (6)Current into Outputs (LOW): 20 mA; (7)Static Discharge Voltage (per MIL-STD-883, Method 3015): > 2001V; (8)Latch-up Current: > 200 mA.
Features
CY7C1354B-166AXCT features: (1)Pin-compatible and functionally equivalent to ZBT; (2)Supports 250-MHz bus operations with zero wait states: Available speed grades are 250, 200 and 166 MHz; (3)Internally self-timed output buffer control to eliminate; (4)the need to use asynchronous OE; (5)Fully registered (inputs and outputs) for pipelined operation; (6)Byte Write capability; (7)Separate VDDQ for 3.3V or 2.5V I/O; (8)Single 3.3V power supply; (9)Fast clock-to-output times; (10)Clock Enable (CEN) pin to suspend operation; (11)Synchronous self-timed writes; (12)Available in 100 TQFP, 119 BGA, and 165 fBGA packages; (13)IEEE 1149.1 JTAG-compatible Boundary Scan; (14)Burst capability條inear or interleaved burst order.
Diagrams
 |
