Product Summary
The AM29LV040B-70JF is a single power supply, 4 Mbit, 3.0 Volt-only Flash memory device organized as 524,288 bytes. The data appears on DQ0-DQ7. The AM29LV040B-90JD is available in 32-pin PLCC and 32-pin TSOP packages. All read, erase, and program operations are accomplished using only a single power supply. The AM29LV040B-70JF can also be programmed in standard EPROM programmers.
Parametrics
AM29LV040B-70JF absolute maximum ratings: (1)Storage Temperature Plastic Packages: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –65℃ to +125℃; (3)Voltage with Respect to Ground: VCC: –0.5 V to +4.0 V, A9, OE#: –0.5 V to +12.5 V, All other pins: –0.5 V to VCC+0.5 V; (4)Output Short Circuit Current: 200 mA.
Features
AM29LV040B-70JF features: (1)Single power supply operation: Full voltage range: 2.7 to 3.6 volt read and write operations for battery-powered applications, Regulated voltage range: 3.0 to 3.6 volt read and write operations and for compatibility with high performance 3.3 volt microprocessors; (2)Manufactured on 0.32 μm process technology; (3)High performance: Full voltage range: access times as fast as 70 ns, Regulated voltage range: access times as fast as 60 ns; (4)Ultra low power consumption (typical values at 5 MHz): Automatic sleep mode: 0.2 μA, Standby mode: 0.2 μA, Read mode: 7 mA, Program/erase mode: 15 mA.
Diagrams
 |
