Product Summary

The CY62128BNLL-55ZXI is a high-performance CMOS static RAM organized as 128K words by 8 bits. Easy memory expansion is provided by an active LOW Chip Enable (CE1), an active HIGH Chip Enable (CE2), an active LOW Output Enable (OE), and tri-state drivers. The CY62128BNLL-55ZXI has an automatic power-down feature that reduces power consumption by more than 75% when deselected.

Parametrics

CY62128BNLL-55ZXI absolute maximum ratings: (1)Storage Temperature: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –55℃ to +125℃; (3)Supply Voltage on VCC to Relative GND: –0.5V to +7.0V; (4)DC Voltage Applied to Outputs in High-Z State: –0.5V to VCC + 0.5V; (5)DC Input Voltage: –0.5V to VCC + 0.5V; (6)Current into Outputs (LOW) : 20 mA; (7)Static Discharge Voltage (per MIL-STD-883, Method 3015): > 2001V; (8)Latch-up Current: > 200 mA.

Features

CY62128BNLL-55ZXI features: (1)Temperature Ranges: Commercial: 0℃ to 70℃; Industrial: –40℃ to 85℃; Automotive-A: –40℃ to 85℃; Automotive-E: –40℃ to 125℃; (2)4.5V-5.5V operation; (3)CMOS for optimum speed/power; (4)Low active power (70 ns Commercial, Industrial, Automotive-A): 82.5 mW (max.) (15 mA); (5)Low standby power (55/70 ns Commercial, Industrial, Automotive-A): 110 μA (max.) (15 μA); (6)Automatic power-down when deselected; (7)TTL-compatible inputs and outputs; (8)Easy memory expansion with CE1, CE2, and OE options; (9)Available in Pb-free and non-Pb-free 32-pin (450 mil-wide) SOIC, 32-pin STSOP and 32-pin TSOP-I.

Diagrams

CY62128BNLL-55ZXI circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CY62128BNLL-55ZXI
CY62128BNLL-55ZXI

IC SRAM 128KX8 PD LP 32-TSOP
Data Sheet
0-1: $3.06
1-25: $2.46
25-100: $2.24
100-250: $2.02
250-500: $1.81
500-1000: $1.53
1000-2500: $1.45
